Autopod Elevation Unit

Autopod is a continuation of the Polecam ethos of providing a "platform" which is a remotely operated programmable telescopic elevation unit for use with Rigs, Cranes, Remote heads, Cameras, Speakers and more..

The unit can be used as a standalone system on a music stage, in a studio, in an orchestral pit, behind a goal, within a conference venue, or a remote location such as a golf course or a race track corner; providing an unobtrusive camera position - great for the spectators whilst not interfering with the artistes, musicians, the players action, presenters or the sequence being shot.
Each AutoPod elevation unit is supplied with a universal camera mounting plate providing the ideal platform for your chosen object to be mounted to. The system also includes a set of "quick release in-line mounting and locking plates" which enables speedy power and data connections via XLR's, rapid deployment and also enables the individual units to be stacked upon each other 2 units high providing greater height to be achieved whilst maintaining a low profile.

Additionally the supplied set of 2x "upstands" can be used to increase elevation height, these are 250mm long and can be stacked accordingly as required.

Future upgrade paths for network connection and variable speed control are anticipated for release middle of 2019

Key Features

  • Elevation Range 55cm to 125cm
  • Payloads up to 35kg
  • Soft Starts and Stops
  • Programmable positioning x 3
  • Remotes via Foot pedal and or hand controller
  • Powered by Mains or 24vdc
  • Modular and stackable
  • Quiet operation
  • Lightweight and portable
  • Packs down in to a lightweight protective roll-along case




Manios



Polecam is delighted to appoint Manios Digital & Film as their partners for Polecam AutoPod systems and Accessories for the United States and Canada.


For more information on Manios Digital, or to schedule a product demo of the Polecam AutoPod (v2) please contact Email: This email address is being protected from spambots. You need JavaScript enabled to view it. or Call 1 (818) 760‐8290.



 spacer
Polecam Autopod
spacer
Autopod Case   Autopod Case   Autopod
spacer
Lightweight Base   Heavy Duty Base Plate   Single Autopod Plus Dolly
spacer
Camera Plate Top Together   Camera Plate Extended   Base Plate
spacer
GoPro's on the Autopod spacer Autopod filming live music spacer Autopod - Panasonic
spacer
  • Description
  • Contents
  • Specifications
  • Recommended

AutoPod is a continuation of the Polecam ethos of providing a "platform" which is a remotely operated programmable telescopic elevation unit for use with Rigs, Cranes, Remote heads, Cameras, Speakers and more..

1.00 AutoPod Desk Control Module
1.00 Autopod Foot Control Pedal
1.00 Autopod Double Case with Foam inserts
1.00 Lightweight Adjustable Base plate
1.00 Polecam ACU (Autopod Control Unit 110-240)
1.00 Elevation Unit
2.00 AutoPod Spacer Rod
2.00 Autopod - quick release V- Lock in-line base clamp
1.00 Autopod - quick release V- Lock in-line leg plate (6pin XLR)
1.00 Autopod - quick release V- Lock in-line mounting plate
1.00 2M - IEC Lead (UK)
1.00 2M - IEC Lead (Euro)
1.00 2M - IEC Lead (USA)
1.00 AutoPod Mains Power Cable
1.00 Autopod leg xlr - xlr extension cable 3 metre
1.00 Camera Mounting Screw
1.00 Allen Key Set
1.00 Riser 75mm-100mm bowl
1.00 100mm flat bowl Adapter

Elevation Range 55cm to 125cm
Payloads up to 35kg

Shipping details
PART #ATP510 82cm x 56cm x 33cm @ 30kg (single elevation system)
PART #ATP520 82cm x 56cm x 33cm @ 39kg (double elevation system)
PART #ATP525 TBA

PART #ATP525 Additional Elevation unit
PART #ATP-150 Heavy Duty Wheeled Base (26kg – 60cm diameter)
PART #ATP-160 Autopod "T" Bar with 3x Camera Mount quick release
PART #TRI300 Folding Wheeled Dolly
PART #ATP011 Autopod 15m Leg Extension Cable
PART #ATP012 Additional Spacer rods



  • Downloads
  • Videos

Autopod ATP510 Autopod #ATP510 (single)
Autopod ATP520 Autopod #ATP520 (double)
Autopod Technical Data Autopod Technical Data
Autopod Users Manual Autopod Operators Manual

Online FlipBook - Autopod Operators Manual
